US7A1 - Additive manufactured tube assembly - Google Patents Connect public, paid and private patent data with Additive manufactured tube assembly Info Publication number US7A1 Authority US Grant status Application Patent type Prior art keywords tube assembly void additive tubes Prior art date 2014-07-03 Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.) Pending Application number US14790907 Inventor Joe Ott John J. Shawn Stempinski Stanley J. Funk Dennis M. Moura Lyutsia Dautova Roger O.

Coffey Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.) United Technologies Corp Original Assignee United Technologies Corp Priority date (The priority date is an assumption and is not a legal conclusion. Manufacturing of tube assemblies such as those containing tubes within tubes (or concentrically located tubes), as one example, require the manufacture of several individual parts then assembly to create the final product. In some examples, air within an annular void defined between the two concentrically located tubes acts as a thermal insulator for fluid that may be flowing through the inner tube. Sealing of this void (i.e. Complete encapsulation) to enhance the thermal properties of the surrounding air is difficult from a manufacturing perspective and not typically accomplished, and if such were accomplished, it would require yet further parts thus limiting feasibility.

Navionics Chart Installer is a Shareware software in the category Miscellaneous developed by Navionics Inc. And Northport Systems Inc. The latest version of Navionics Chart Installer is currently unknown.

1 illustrates a fuel nozzle for a gas turbine engine as one, non-limiting, example of an additive manufactured tube assembly 20. The fuel nozzle 20 is part of a combustor 22 that may be annular in shape and concentrically disposed to an engine axis A.

The combustor 22 may further include a bulkhead assembly 24, an outer wall 26, an inner wall 28, and a diffuser case module 34. The outer and inner walls 26, 28 project axially in a downstream direction from the bulkhead assembly 24, and radially define an annular combustion chamber 30 therebetween.

An annular cooling plenum 32 is generally defined radially between the outer diffuser case module 34 and a diffuser inner case 36 of the engine. The bulkhead assembly 24 and walls 26, 28 are located in the cooling plenum 32 immediately downstream from a compressor section 38, and upstream from a turbine section 40 of the engine. The annular bulkhead assembly 24 may extend radially between and is secured to the forward most ends of the walls 26, 28. Assembly 24 generally includes an annular hood 42, a wall or heat shield 44 that defines the axial upstream end of the combustion chamber 30, and a plurality of swirlers 46 (one shown) spaced circumferentially about engine axis A and generally projecting or communicating through the wall 44. A plurality of circumferentially distributed hood ports 48 accommodate a respective plurality of the fuel injectors or nozzles 20 as well as direct compressed air C into the forward end of the combustion chamber 30 through the associated swirler 46. Each fuel nozzle 20 may receive fuel from at least one fuel manifold 50 generally located radially outward of the case module 34. The elongated fuel nozzle 20 may substantially extend longitudinally along a centerline 52 and in a radial inward direction with respect to the engine axis A, through the case module 34 and into the plenum 32.

The centerline 52 and thus the nozzle 20 then bends (i.e. See bend 54) and projects in an axial downstream direction, extending through the hood port 48 and into the swirler 46 where fuel is then dispensed and atomized from the nozzle 20. Referring to FIG. 2, the tube assembly 20 (i.e.

A simplified fuel nozzle in the present example) may have a first or inner tube 56 co-extending with and surrounded by (e.g. Concentrically located) to a second or outer tube 58. The outer tube 58 may be spaced radially outward from the inner tube 56 thereby defining a substantially annular void 60, there-between. Void 60 may generally be sealed (i.e. Completely encapsulated) from the plenum 32 and/or surrounding environment to act as a thermal insulator for any fluid (see arrow 62) flowing through the inner tube 56. To enhance the thermal insulating properties, the void 60 may be under a negative atmospheric pressure and may further contain an inert gas such as nitrogen (N2), Argon or any other gas compatible with the material composition of the surrounding structures.

Although liquid fuel in the present example, it is contemplated and understood that the fluid 62 may also be a gas, liquid such as oil and water, or even a solid material (e.g. Powder) capable of flow. It is further understood that the term “tube” also refers to conduits, casings, pipes and other structures capable of fluid flow and/or encasement of a thermal insulating gas. Such fuel nozzles 20 flowing liquid fuel and operating in hot environments like the plenum 32 where temperatures may exceed 1,700 degrees Fahrenheit (927 degrees Celsius) are susceptible to fuel varnishing and coking due to high temperatures of more traditional fluid bearing tube(s). This coking can lead to decreased flow capacity of the nozzle and decreased quality of fuel delivery.

To manage the temperature of the tube 56 and thus the fluid or fuel 62 and prevent coking, the void 60 is employed to break the thermal conduction path from the hot external environment to the inner tube 56. It is further contemplated and understood that other portions of a fuel delivery system of the gas turbine engine may employ the same type of assembly 20. For instance, the fuel manifold 50 may be susceptible to similar coking issues leading to unintentional mal-distribution of fuel in the system, and thus benefit from the same means of insulating a tube bearing fluid flow. The inner and outer tubes 56, 58 may each have at least one respective bend 64, 66 that generally corresponds with the bend(s) 54 of the centerline 52 and such that the void 60 is generally maintained (i.e. Spacing between tubes).

The bends 64, 66 may be such where longitudinal insertion of the inner tube 56 into the outer tube 58 (and if the tubes were separate pieces) is not possible. With such fitting difficulties, additive manufacturing the tubes 56, 58 generally together and/or simultaneously is advantageous. As an example of such insertion difficulties that the additive manufacturing process resolves, the outer tube 58 may be lacking any line-of-site through the tube and the inner tube 56 is too large to freely fit completely into the outer tube 58. More specifically, the outer tube 58 may have an inner diameter (see arrow 68) and two substantially straight portions 70, 72 projecting outward from respective opposite ends of the bend 66. The straight portions 70, 72 and have respective longitudinal lengths (see respective arrows 74, 76) that are substantially longer than the inner diameter 68. The inner tube 56 may similarly have substantially straight portions 78, 80 projecting outward from respective ends of the bend 64.

The straight portions 78, 80 may have respective longitudinal lengths (see respective arrows 82, 84) that are each longer than the inner diameter 68 of the outer tube 58. In such a dimensional relationship, fitting of the inner tube 56 into the outer tube 58 may be difficult if not impossible.

Alternatively, each tube may have multiple bends along the centerline 52 that may be directed in different directions, this multiple bend configuration would also make fitting or insertion of the inner tube 56 into the outer tube 58 difficult, if not impossible. The fuel nozzle 20 may further have a pressure release or maintenance feature 86 supported by and communicating through the outer tube 58 for creating and maintaining the vacuum or negative atmospheric pressure in the void 60. The feature 86 may further assist in restoring the vacuum after a repair procedure or rupture of the outer tube 58. The feature 86 may be additive manufactured as one unitary piece to the assembly or may be adhered and/or brazed to the outer wall 58 after additive manufacturing is completed. The negative atmospheric pressure may be about three pounds per square inch (21 kPa). The fuel nozzle 20 may include at least one support structure 88 for properly locating the inner tube 56 with respect to the outer tube 58.

The support structure 88 may be generally located at one or both of the distal ends of the fuel nozzle 20 (e.g. The distal joinder of the inner tube 56 to the outer tube 58. Alternatively, or in addition thereto, the support structure 88 may be a plurality of pylons that traverse the void 60 and connect the inner tube 56 to the outer tube 58.

Such pylons are spaced axially and circumferentially with respect to the centerline 52, may be additively manufactured as one unitary piece to both of the tubes 56, 58, and are minimal in mass to limit thermal conduction from the outer tube to the inner tube. The number of pylons are dictated by the structural needs of the fuel nozzle or assembly 20 and may be about 0.004 inches (0.102 millimeters) in diameter, or the minimal production capability of the additive manufacturing process. Referring to FIG. 3, a second embodiment of a tube assembly is illustrated wherein like elements have like identifying numerals except with the addition of a prime symbol. The tube assembly 20′ of the second embodiment has a support structure 88′ that is generally of a honeycomb orientation. The honeycomb may function to divide the annular void 60′ into a plurality of individually sealed void portions 90. It is further contemplated and understood that use of the term “honeycomb” may include a vascular and/or lattice structure, strut configurations, and/or a generally porose material.

Yet further, the density of the honeycomb may be increased where additional support strength is needed. The supports may also be solid or organic in shape. Referring to FIG. 4, a third embodiment of a tube assembly is illustrated wherein like elements have like identifying numerals except with the addition of a double prime symbol. The tube assembly 20″ of the third embodiment has a support structure 88′ that is girder-like. That is, a plurality of pylons may be paired such that the ends of two pylons 92, 94 and the inner tube 56 connect to one-another at a junction 96 and the opposite ends of the respective pylons 92, 94 are spaced from one-another and individually connect to the outer tube 58.

In this way, minimal contact is made with the inner tube 56, thereby reducing thermal conduction. Examples of additive manufacturing processes include, but are not limited to, laser powder bed, electron beam melting, free form fabrication laser powder deposition and electron beam wire deposition, amongst others. Additive manufacturing systems include, for example, Additive Layer Manufacturing (ALM) devices, such as Direct Metal Laser Sintering (DMLS), Selective Laser Melting (SLM), Laser Beam Melting (LBM) and Electron Beam Melting (EBM) that provide for the fabrication of complex metal, alloy, polymer, ceramic and composite structures by the freeform construction of the workpiece, layer-by-layer. The principle behind additive manufacturing processes may involve the selective melting of atomized precursor powder beds by a directed energy source, producing the lithographic build-up of the workpiece. The melting of the powder occurs in a small localized region of the energy beam, producing small volumes of melting, called melt pools, followed by rapid solidification, allowing for very precise control of the solidification process in the layer-by-layer fabrication of the workpiece. These devices are directed by three-dimensional geometry solid models developed in Computer Aided Design (CAD) software systems. One example of an additive manufacturing system 100 capable of manufacturing the tube assembly 20 is schematically illustrated in FIG.
